S25
| Outline(L x W x H)mm: 34.8 x 38.0 x 56.3 |
| ● 20A/30A general purpose power relay |
| ● SPDT,DPDT and TPDT contact configurations |
| ● DC and AC coil |
| ● Socket and PCB terminal available |
S23
| Outline(L x W x H)mm: 34.8 x 38.0 x 56.3 |
| ● 30A general purpose Power Relay. |
| ● SPDM, SPDB, SPDM+DB contact configurations. |
| ● AC & DC coils are both available. |
S20H
| Outline(L x W x H)mm: 29.0 x 12.7 x 15.7 |
| ● High rating miniature PCB relay. |
| ● Low power consumption 400mW coil. |
| ● Low height 15.7mm. |
| ● 20A 277VAC/SPDT, 10A 277VAC/DPDT rating are approved. |
S20M
| Outline(L x W x H)mm: 29.0 x 12.7 x 15.7 |
| ● High rating miniature PCB relay. |
| ● Low power consumption 400mW coil. |
| ● Low height 15.7mm. |
| ● 20A 277VAC/SPDT, 10A 277VAC/DPDT rating are approved. |
S20H
| Outline(L x W x H)mm: 29.0 x 12.7 x 15.7 |
| ● High rating miniature PCB relay. |
| ● Low power consumption 400mW coil. |
| ● Low height 15.7mm. |
| ● 20A 277VAC/SPDT, 10A 277VAC/DPDT rating are approved. |
S22
| Outline(L x W x H)mm: 20.2 x 16.5 x 20.0 |
| ● Small footprint. |
| ● Miniature PCB surge cube relay. |
| ● Reverse contact terminal position version is available. |
| ● SPNO, SPNC, SPDT and Sealed flux free & sealed Washable type are available. |
S21
| Outline(L x W x H)mm: 20.5 x 7 x 15.3 |
| ● 0.36W and 0.2W coil are available. |
| ● Switching capacity relay for high density. |
| ● Standard PC layout. |
| ● SPNO configuration. |
| ● Sealed type available. |
S20E
| Outline(L x W x H)mm: 29.0 x 12.7 x 15.7 |
| ● High rating miniature PCB relay. |
| ● Low power consumption 400mW coil. |
| ● Low height 15.7mm. |
| ● 20A 277VAC/SPDT, 10A 277VAC/DPDT rating are approved. |
S22
| Outline(L x W x H)mm: 20.2 x 16.5 x 20.0 |
| ● Small footprint. |
| ● Miniature PCB surge cube relay. |
| ● Reverse contact terminal position version is available. |
| ● SPNO, SPNC, SPDT and Sealed flux free & sealed Washable type are available. |
S21
| Outline(L x W x H)mm: 20.5 x 7 x 15.3 |
| ● 0.36W and 0.2W coil are available. |
| ● Switching capacity relay for high density. |
| ● Standard PC layout. |
| ● SPNO configuration. |
| ● Sealed type available. |
S20E
| Outline(L x W x H)mm: 29.0 x 12.7 x 15.7 |
| ● High rating miniature PCB relay. |
| ● Low power consumption 400mW coil. |
| ● Low height 15.7mm. |
| ● 20A 277VAC/SPDT, 10A 277VAC/DPDT rating are approved. |
